| Specification (Optional) | ||||||
| Longest range | 68KM | Top speed | 40KM/H (45KM/H) | |||
| Motor type | 60V30H(35H)10" | Power of motor | 500W (800W) | |||
| Max torque(N.M) | 83 (96) @27rpm | Max power (KW) | 1.48 (1.72) @520rpm | |||
| Controller | High efficiency, brushless vector controller | |||||
| Type of battery | VRLA | Est. life to 80%: Recycle 300times, 20000KM | ||||
| Model of battery | 60V20AH | Capacity of battery | 1.2KWh | |||
| Input: AC110/220V, 50～60HZ | Charge time | 8H 100%, 7H 95% | ||||
| Front / Rear suspension: Telescopic hydraulic / Spring damping | ||||||
| Front / Rear brake | Disc/ Drum(Disc) | Front / Rear tyre | F80/100-10 R80/100-10 | |||
| L/W/H(mm) | 1730×700×1030 | Equivalent fuel economy: 0.25 Liter/100KM | ||||
| Wheelbase | 1300mm | Seat height | 720mm | |||
| Climbing ability | 16° | Ground clearance | 125mm | |||
| Maximum load | 150kg | Curb weight | 95kg | |||
| E-motor Warranty | 2 years | Battery Warranty | 1 year | |||
